| Wavelengths | 1310 nm | 1490 nm | 1550 nm |
|---|
| Measurement Mode | Simultaneous 3-channel power measurement |
|---|
| Power Range | -50 dBm to +26 dBm |
|---|
| Resolution | 0.01 dB | 0.001 mW |
|---|
| Accuracy | +/- 0.25 dB (at reference wavelength, 23 C) |
|---|
| Display Units | dBm | dBr | mW (user selectable) |
|---|
| Detector Type | InGaAs photodiode |
|---|
| Optical Connector | SC/APC (SC/UPC adapter included) |
|---|
| Connector Interface | SC adapter port with 2.5 mm ferrule |
|---|
| Data Storage | Up to 99 measurement records (SAVE function) |
|---|
| Data Interface | USB 2.0 (data transfer and firmware upgrade) |
|---|
| Battery | 3 x AA alkaline batteries |
|---|
| Battery Life | >= 40 hours continuous operation |
|---|
| Auto Power-Off | Configurable: 5 / 10 / 15 min or disabled |
|---|
